Container box 2 buttons
€18.00
VAT excluded
The 74 PS series is a system of buttons, selectors and indicators with a diameter of 22 mm with IP66 protection rating
The 74 PS series is a system of buttons, selectors and indicators with a diameter of 22 mm with IP66 protection rating which allows you to create a real interface between man and machine and, at the same time, to control the operating status of the drives and equipment, ensuring high safety standards.
Finally, 6 types of empty containers from 1 to 12 places or already filled containers are available in the range. complete with buttons and contacts.
Technical Data:
No. of places: 2 - Colour: Gray RAL 7035 - Type: knock-out Removable with tool - Side entries: 6 x Ø 23 - Higher income: 1 x Ø 23 - Lower revenue: 1 x Ø 23 - Degree of protection: IP66 - Insulation class: II - Impact resistance IK07 - Cover screws: Stainless steel - Screw tightening torque: 0.8 NM - External dimensions B x H x D (mm): 132 x 82 x 65 - Glow Wire Test: 650 °C - Thermopressure with ball: 70 °C - Reference standard: EN 60670-1 - Temperature of installation: -25 +60 °C - Electrocod code: 0212 - Ware number: 85381000
EIN0016
New
